faCtOrY SettinGS & ranGeS
single section
Description Factory Setting Range
Machine Type Front Wheel
GPS Antenna Height 12.5 ft
3.81 m
0.0 to 32.81 ft
0.0 to 10.0 m
Implement Type Straight
Implement Offset
Distance
0.0 ft
0.0 m
0.0 to 32.81 ft
0.0 to 10.0 m
Implement Offset
Direction
Right
Guidance Width 60.0 ft
18.288 m
3.28 to 246.06 ft
1.0 to 75.0 m
Application Width /
Working Width
12.0 ft
3.6576 m
3.28 to 246.06 ft
1.0 to 75.0 m
Applied Area Alarm Disabled
Exit Alarm 0.0 sec 0.0 to 10.0 sec
Entry Alarm 0.0 sec 0.0 to 10.0 sec
Straight Implement Type
Description Factory Setting Range
Boom Offset Direction Backwards
Antenna to Boom 0.0 ft
0.0 m
0.0 to 164.04 ft
0.0 to 50.0 m
TeeJet Spreader Implement Type
Description Factory Setting Range
Setup Type TeeJet
Antenna to Disks 0.0 ft
0.0 m
0.0 to 164.04 ft
0.0 to 50.0 m
Spread Offset Distance 0.0 ft
0.0 m
0.0 to 246.06 ft
0.0 to 75.0 m
Spread Length 0.0 ft
0.0 m
0.0 to 246.06 ft
0.0 to 75.0 m
OEM Spreader Implement Type
Description Factory Setting Range
Setup Type OEM
Antenna to Disks 0.0 ft
0.0 m
0.0 to 164.04 ft
0.0 to 50.0 m
Start Distance Consult spreader manufacturer for
value
Stop Distance Consult spreader manufacturer for
value
smartCable or section driver Module
Description Factory Setting Range
Machine Type Front Wheel
GPS Antenna Height 12.5 ft
3.81 m
0.0 to 32.81 ft
0.0 to 10.0 m
Implement Type Straight
Symmetric Implement
Layout
Enabled
Number of Implement
Sections
Depends on cable or SDM
Guidance Width 60.0 ft
18.288 m
3.28 to 246.06 ft
1.0 to 75.0 m
Application Width /
Working Width
Total for all sections must be greater
than 3.28 ft / 1.0 m.
Section Width 12.0 ft
3.6576 m
0.0 to 246.06 ft
0.0 to 75.0 m
Straight Implement Type
Description Factory Setting Range
Boom Offset Direction Backwards
Antenna to Boom 0.0 ft
0.0 m
0.0 to 164.04 ft
0.0 to 50.0 m
Overlap 50%
Delay On Time 1.0 sec 0.0 to 10.0 sec
Delay Off Time 1.0 sec 0.0 to 10.0 sec
TeeJet Spreader Implement Type
Description Factory Setting Range
Setup Type TeeJet
Antenna to Disks 0.0 ft
0.0 m
0.0 to 164.04 ft
0.0 to 50.0 m
Overlap 50%
Delay On Time 0.0 sec 0.0 to 10.0 sec
Delay Off Time 0.0 sec 0.0 to 10.0 sec
Spread Offset Distance 0.0 ft
0.0 m
0.0 to 246.06 ft
0.0 to 75.0 m
Section Offset 0.0 ft
0.0 m
0.0 to 246.06 ft
0.0 to 75.0 m
Spread Length 0.0 ft
0.0 m
0.0 to 246.06 ft
0.0 to 75.0 m
