RealView setup Options
RealView setup options accesses additional guidance tools
including guidance over video and a steering angle indicator.
To access RealView options:
1. Press REALVIEW OPTIONS tab to display RealView
options
2. Press REALVIEW GUIDANCE OPTIONS icon .
3. Select from:
►Guidance Over Video – places three dimensional
guidelines over the video feed for navigation assistance
►Steering Angle Indicator – displays the direction in which
the steering wheel needs to be adjusted
►Horizon Line Adjustment – adjusts the on screen
horizon line up or down
Figure 6-40: RealView Setup Options
0.0
mph
0.00
ac
> 0.0 <
0.0
mph
0.00
ac
> 0.0 <
0.0
mph
0.00
ac
> 0.0 <
