Interlogix GE-DSH-73 Series User Manual User Manual
Page 35

Chapter 2: Installation
GE-DSH-73/DSH-82 and DSH-82-PoE User Manual
31
Figure 2-20
:
LC fiber optical cable connects to the transceiver
• Remove the transceiver module
1. Make sure there is no network activity by consulting or checking with the network
administrator or through the management interface of the switch/converter (if
available) to disable the port in advance.
2. Remove the Fiber Optic Cable gently.
Figure 2-21
:
Pull out the SFP transceiver
3. Turn the handle of the MGB module horizontally.
4. Pull out the module gently through the handle.
