Chapter 2: Installation
14
GE-DSH-73/DSH-82 and DSH-82-PoE User Manual
The Front Panel and Rear Panel of the GE-DSH-82-PoE Managed Industrial Switch are
shown below:
Figure 2-5
:
Front and Rear Panel of GE-DSH-82-PoE
1. Model Name
9. 10/100/1000Base-T port
2. System Power: LED
10. 1000Base-SX/LX SFP slot
3. Ring Master: LED indicator
11. LED indicators for 1000Base-SX/LX ort
4. LED for power 1 input
12. LED indicators for PoE power output
5. LED for power 2 input
13. 6-Pin Terminal Block
6. FAULT: LED indicator
14. Ground Screw
7. RJ-45 type RS-232 Console
15. Screw holes for Wall Mounting kit
8. 8 x 10/100Base-TX port
16. DIN-Rail Kit
