Chapter 2: Installation
22
GE-DSH-73/DSH-82 and DSH-82-PoE User Manual
• PoE port link – Port-1 to Port-8
LED
Color
Status
Meaning
On
An IEEE 802.3af PoE power device is detected.
FWD
(P1 to P8)
Green
Off
No IEEE 802.3af PoE power device attached
• 10/100/1000Base-T / SFP combo interface - Port-9, Port-10
LED
Color
Status
Meaning
On
A network device is detected.
Blinking
The port is transmitting or receiving packets from
the TX device.
Green
(Upper LED)
Off
No device attached
On 1000M
Port 9, Port 10
(RJ-45)
Green
(Lower LED)
Off 10/100M
On
The SFP port is linking
Blinking
The port is transmitting or receiving packets from
the TX device.
Link/Active (P9,
P10 SFP)
Green
Off
No device attached
