GE-DSH-73/DSH-82 and DSH-82-PoE User Manual

11

Chapter 2

Installation

Hardware Description

Physical Dimensions

GE-DSH-82

(W x D x H): 2.83” x 4.13” x 5.98” / 72mm x 105mm x 152mm.

Figure 2-1

:

GE-DSH-82 panel layout
