Evco S.p.A.

c-pro 3 CLIMA sistema | Installer manual ver.1.1 | Code 144CP3CSE114

page 57 of 74

Baud rate

-20Kbit

-50Kbit

-125Kbit

-500Kbit

General parameters

MODBUS network

Idx

Modbus serial address

1

1

247

General parameters

MODBUS network

Baud

Modbus communication speed (baud rate)

- 1200Kb

- 2400Kb

- 4800Kb

- 9600Kb

- 19200Kb

9600Kb

1200Kb

19200Kb

General parameters

MODBUS network

Parity

Type of Modbus communication parity

- NO

- ODD

- EVEN

EVEN

NO

EVEN

General parameters

MODBUS network

Stop

Modbus communication Bit Stop position

1b

1b

2b

SOLAR PANELS

Solar panels

Probes offset

Panel 1

Solar panel 1 water temperature transducer (offset)

calibration

(expressed in °C)

0.0

-10.0

10.0

Solar panels

Probes offset

Panel 2

Solar panel 2 water temperature transducer (offset)

calibration

(expressed in °C)

0.0

-10.0

10.0


7.7

Unit status

The state of ON-OFF controller MCPS is given by the state regulator central heat MCCT.

8

Regulations

In this chapter you will find all the major adjustments made by the c-pro 3 CLIMA sistema.

At the side of the title of every paragraph, in brackets find the control module or modules involved in these

regulations.

It can therefore be immediately understood from which application to set the function and if the function is available or

not in the system available, depending on the presence or not of the control modules indicated.

8.1

Regulation of the zone temperature

(MCZN, MCCT modules)

8.1.1

Regulation principle

Depending on the system functioning mode (summer or winter) and the time band active in every zone regulated by

the system (manual, night, holiday, economy, comfort in summer and manual, anti-freeze, comfort in winter), when

the temperature detected by the room probe is over (summer) or below (winter) the active zone set-point value plus
