Evco S.p.A.

c-pro 3 CLIMA sistema | Installer manual ver.1.1 | Code 144CP3CSE114

page 34 of 74

PV22

Climatic curve min. external temperature (winter)

-5.0

-30.0

30.0

PV23

Climatic curve max. external temperature (winter)

10.0

0.0

30.0

PV24

Climatic curve setpoint (winter)

35.0

0.0

90.0

PV72

Min. value

0

0

100

PV73

Max. value

100

0

100

INSTALLER PARAMETERS: MIXING VALVE3

PV25

Mode
0:Closed
1:Modul.
2:Fix

Modul.

Closed

Fix

PV26

Fix opening

20

0

100

PV27

Proportional band

5.0

0.0

10.0

PV28

Integral time [sec]

0

0

65535

PV29

Dew point offset

3.0

-10.0

10.0

PV30

Climatic curve min. external temperature (summer)

10.0

0.0

30.0

PV31

Climatic curve max. external temperature (summer)

30.0

10.0

60.0

PV32

Climatic curve setpoint (summer)

7.0

0.0

40.0

PV33

Climatic curve min. external temperature (winter)

-5.0

-30.0

30.0

PV34

Climatic curve max. external temperature (winter)

10.0

0.0

30.0

PV35

Climatic curve setpoint (winter)

35.0

0.0

90.0

PV74

Min. value

0

0

100

PV75

Max. value

100

0

100

INSTALLER PARAMETERS: MIXING VALVE4

PV36

Mode
0:Closed
1:Modul.
2:Fix

Modul.

Closed

Fix

PV37

Fix opening

20

0

100

PV38

Proportional band

5.0

0.0

10.0

PV39

Integral time [sec]

0

0

65535

PV40

Dew point offset

3.0

-10.0

10.0

PV41

Climatic curve min. external temperature (summer)

10.0

0.0

30.0

PV42

Climatic curve max. external temperature (summer)

30.0

10.0

60.0

PV43

Climatic curve setpoint (summer)

7.0

0.0

40.0

PV44

Climatic curve min. external temperature (winter)

-5.0

-30.0

30.0

PV45

Climatic curve max. external temperature (winter)

10.0

0.0

30.0

PV46

Climatic curve setpoint (winter)

35.0

0.0

90.0

PV76

Min. value

0

0

100

PV77

Max. value

100

0

100

INSTALLER PARAMETERS: MIXING VALVE5

PV47

Mode
0:Closed
1:Modul.
2:Fix

Modul.

Closed

Fix

PV48

Fix opening

20

0

100

PV49

Proportional band

5.0

0.0

10.0

PV50

Integral time [sec]

0

0

65535

PV51

Dew point offset

3.0

-10.0

10.0

PV52

Climatic curve min. external temperature (summer)

10.0

0.0

30.0

PV53

Climatic curve max. external temperature (summer)

30.0

10.0

60.0

PV54

Climatic curve setpoint (summer)

7.0

0.0

40.0

PV55

Climatic curve min. external temperature (winter)

-5.0

-30.0

30.0

PV56

Climatic curve max. external temperature (winter)

10.0

0.0

30.0

PV57

Climatic curve setpoint (winter)

35.0

0.0

90.0

PV78

Min. value

0

0

100

PV79

Max. value

100

0

100

INSTALLER PARAMETERS: MIXING VALVE6

PV58

Mode
0:Closed
1:Modul.
2:Fix

Modul.

Closed

Fix

PV59

Fix opening

20

0

100

PV60

Proportional band

5.0

0.0

10.0

PV61

Integral time [sec]

0

0

65535

PV62

Dew point offset

3.0

-10.0

10.0

PV63

Climatic curve min. external temperature (summer)

10.0

0.0

30.0

PV64

Climatic curve max. external temperature (summer)

30.0

10.0

60.0

PV65

Climatic curve setpoint (summer)

7.0

0.0

40.0

PV66

Climatic curve min. external temperature (winter)

-5.0

-30.0

30.0

PV67

Climatic curve max. external temperature (winter)

10.0

0.0

30.0
