Evco S.p.A.

c-pro 3 CLIMA sistema | Installer manual ver.1.1 | Code 144CP3CSE114

page 35 of 74

PV68

Climatic curve setpoint (winter)

35.0

0.0

90.0

PV80

Min. value

0

0

100

PV81

Max. value

100

0

100

INSTALLER PARAMETERS: ALARMS

PA01

Enabling pumps operation time hours alarm

Enab.

Disab.

Enab.

PA02

Enabling boiler operation time hours alarm

Enab.

Disab.

Enab.

PA03

Enabling CH-HP operation time hours alarm

Enab.

Disab.

Enab.

PA04

Pumps alarm delay [sec]

0

0

999

PA05

Flow switch alarm delay at start [sec]

30

0

255

PA06

Flow switch alarm delay [sec]

5

0

255

PA07

Max. alarm flow alarm for manual

3

0

255

PA08

Return for alarm delta temperature

3.0

0.0

20.0

PA09

Return temperature alarm delay

180

0

999

PA10

Set HT linea1

45.0

0.0

90.0

PA11

Diff. HT linea1

5.0

0.0

10.0

PA12

Set LT linea1

10.0

-10.0

40.0

PA13

Diff. LT linea1

5.0

0.0

10.0

PA14

Set HT linea2

80.0

0.0

90.0

PA15

Diff. HT linea2

5.0

0.0

10.0

PA16

Set LT linea2

4.0

-10.0

40.0

PA17

Diff. LT linea2

5.0

0.0

10.0

PA18

Set HT linea3

45.0

0.0

90.0

PA19

Diff. HT linea3

5.0

0.0

10.0

PA20

Set LT linea3

10.0

-10.0

40.0

PA21

Diff. LT linea3

5.0

0.0

10.0

PA22

Set HT linea4

80.0

0.0

90.0

PA23

Diff. HT linea4

5.0

0.0

10.0

PA24

Set LT linea4

4.0

-10.0

40.0

PA25

Diff. LT linea4

5.0

0.0

10.0

PA26

Set HT linea5

45.0

0.0

90.0

PA27

Diff. HT linea5

5.0

0.0

10.0

PA28

Set LT linea5

10.0

-10.0

40.0

PA29

Diff. LT linea5

5.0

0.0

10.0

PA30

Set HT linea6

80.0

0.0

90.0

PA31

Diff. HT linea6

5.0

0.0

10.0

PA32

Set LT linea6

4.0

-10.0

40.0

PA33

Diff. LT linea6

5.0

0.0

10.0

INSTALLER PARAMETERS: OTHERS

PH01

Language
0:English
1:Italian

English

English

Italian

PH02

Kind of unit On/Off
0:DI
1:BMS

DI

DI

BMS

PH03

Kind of changeover
0: None
1: BMS
2: DI
3: Automatic

Auto

---

Auto

PH05

CAN address

1

1

127

PH06

CAN Baudrate
0:20K
1:50K
2:125K
3:500K

50K

20K

500K

PH07

Enable public V-Graph

YES

NO

YES

PH11

Modbus address

1

1

247

PH12

Modbus Baud [Kbit]
0:1200
1:2400
2:4800
3:9600
4:19200

9600

1200

19200

PH13

Modbus parity
0:None
1:Odd
2:Even

Even

None

Even

PH14

Modbus Stopbit
0:1 bit
1: 2 bit

1 bit

1 bit

2 bit
