Evco S.p.A.

c-pro 3 CLIMA sistema | Installer manual ver.1.1 | Code 144CP3CSE114

page 47 of 74

PF08

Heating fancoil 1 delay [min]

5

1

255

PF09

Heating fancoil 2 delta

1.0

0.0

10.0

PF10

Heating fancoil 2 delay [min]

5

1

255

INSTALLER PARAMETERS: ALARMS

PA01

Dehumidificator alarm delay [sec]

0

0

65535

PA02

Kind of dehumidificator alarm

Auto

auto

Manu

PA03

Anti-freeze setpoint

3.0

-10.0

30.0

PA04

Anti-freeze band

1.0

-10.0

30.0

INSTALLER PARAMETERS: OTHERS

PH05

Kind of V-room visualizations
1: Separate zones
2: all zones in a single V-room

Zone sep.

Zone sep.

All

PH06

Baudrate CAN
0:20K
1:50K
2:125K
3:500K

50K

20K

500K

PH11

Modbus address

1

1

247

PH12

Baud Modbus[Kbit]
0:1200
1:2400
2:4800
3:9600
4:19200

9600

1200

19200

PH13

Modbus parity
0:None
1:Odd
2:Even

Even

None

Even

PH14

Stopbit Modbus
0:1 bit
1: 2 bit

1 bit

1 bit

2 bit

MANUFACTOR PARAMETERS: AI

PH50

Sensor AI1:
1: PTC
2: NTC
3: 0-20mA
4: 4-20mA
5: 0-5V
6: 0-10V
7: PT1000
8: NTC 10K-2
9: NTC 10K-3

NTC

PTC

NTC 10K-

3

PH51

Sensor AI2

NTC

PTC

NTC 10K-

3

PH52

Sensor AI3

NTC

PTC

NTC 10K-

3

MANUFACTOR PARAMETERS: DI

PH53

Kind of DI1:
0: ---
1: Zone ON/OFF
2: Zone alarm
3: Zone temperature external thermostat
4: Zone humidity external thermostat

Termo.T.

---

Termo.U.

PH54

Kind of DI2:
0: ---
1: Zone ON/OFF
2: Zone alarm
3: Zone temperature external thermostat
4: Zone humidity external thermostat

Termo.T.

---

Termo.U.

PH55

Kind of DI3:
0: ---
1: Zone ON/OFF
2: Zone alarm
3: Zone temperature external thermostat
4: Zone humidity external thermostat

Termo.T.

---

Termo.U.

PH56

Kind of DI4:
0: ---
1: Zone ON/OFF
2: Zone alarm
3: Zone temperature external thermostat
4: Zone humidity external thermostat

Termo.T.

---

Termo.U.

PH57

Kind of DI5:

Termo.T.

---

Termo.U.
