background image

Evco S.p.A.

c-pro 3 CLIMA sistema | Installer manual ver.1.1 | Code 144CP3CSE114

page 16 of 74

3.4

Regulators network configuration

The c-pro 3 CLIMA sistema is based on the CANbus communication between the various control modules present in

the network, with the following maximum configuration:

N° 1 c-pro 3 hecto+ MCCT thermal power plant regulator regulator and c-pro 3 EXP hecto+ by request

N° 8 c-pro 3 hecto+ MCZN zone regulators

N° 1 regulator for c-pro 3 hecto+ MCPS solar panels

Every controller present in the network must be assigned with a different and specific CANbus address, according to

the logic position of the controller inside the c-pro 3 CLIMA sistema, following the layout given below:

Type of controller

Controller code

CANbus

address

Thermal power plant regulator

c-pro 3 hecto+ MCCT

1 (default)

Expansion

c-pro 3 EXP hecto+ MCCT

11

Zone 1 regulator (zones 1-2)

c-pro 3 hecto+ MCZN

2 (default)

Zone 2 regulator (zones 3-4)

c-pro 3 hecto+ MCZN

3

Zone 3 regulator (zones 5-6)

c-pro 3 hecto+ MCZN

4

Zone 4 regulator (zones 7-8)

c-pro 3 hecto+ MCZN

5

Zone 5 regulator (zones 9-10)

c-pro 3 hecto+ MCZN

6

Zone 6 regulator (zones 11-12)

c-pro 3 hecto+ MCZN

7

Zone 7 regulator (zones 13-14)

c-pro 3 hecto+ MCZN

8

Zone 8 regulator (zones 15-16)

c-pro 3 hecto+ MCZN

9

Regulator for solar panels

c-pro 3 hecto+ MCPS

17 (default)

As highlighted in the previous table, the controllers are set by default to be automatically recognised in network as:

thermal power plant regulator CANbus 1 address

zone 1 regulator CANbus 2 address

regulator for solar panels CANbus 17 address
