Evco S.p.A.

c-pro 3 CLIMA sistema | Installer manual ver.1.1 | Code 144CP3CSE114

page 42 of 74

6.3.4

Manufactor menu

The menu manufactor is level 4, that is used to enter the password level builder to be able to view/edit the parameters

in this branch.

- Menu AI: AI entering the menu you can configure the types of sensors.

- Menu DI: entering the menu you can configure the function associated with each DI, its logic and the assignment to

the desired zone.

- Menu DO: DO entering the menu you can then configure the logic of use.

6.4

Pages On/Off

By accessing the pages of On/Off Controller MCZN you have the ability to view the system status (On/Off), the season,

the state of the network module MCCT and the presence of alarms.

6.5

Configuration Parameters

The following task map lists all the configuration parameters contained in the maintenance menu, installer and

manufacturer MCZN managed by the application.

For each parameter is also provided a brief description, the range of permissible values, the unit of measure and the

default value proposed.

The menus are structured according to the logic stated in the respective paragraphs of description.

6.5.1

List of configuration parameters


Label

Parameter description

Default

Min

Max

MAINTENANCE PARAMETERS: MANUAL

PM10

Enable manual mode DO1

Disab.

0:Disab.

1:Enab.

PM11

Force manual DO1

OFF

OFF

ON

PM12

Enable manual mode DO2

Disab.

0:Disab.

1:Enab.

PM13

Force manual DO2

OFF

OFF

ON

PM14

Enable manual mode DO3

Disab.

0:Disab.

1:Enab.

PM15

Force manual DO3

OFF

OFF

ON

PM16

Enable manual mode DO4

Disab.

0:Disab.

1:Enab.

PM17

Force manual DO4

OFF

OFF

ON

PM18

Enable manual mode DO5

Disab.

0:Disab.

1:Enab.

PM19

Force manual DO5

OFF

OFF

ON

PM20

Enable manual mode DO6

Disab.

0:Disab.

1:Enab.

PM21

Force manual DO6

OFF

OFF

ON

MAINTENANCE PARAMETERS: CALIBRATION

PM80

Offset T. Z1

0.0

-10.0

10.0

PM81

Offset T. Z2

0.0

-10.0

10.0

PM82

Offset T. Z3

0.0

-10.0

10.0

PM83

Offset T. Z4

0.0

-10.0

10.0

PM84

Offset T. Z5

0.0

-10.0

10.0

PM85

Offset T. Z6

0.0

-10.0

10.0

PM86

Offset H. Z1

0.0

-10.0

10.0

PM87

Offset H. Z2

0.0

-10.0

10.0

PM88

Offset H. Z3

0.0

-10.0

10.0

PM89

Offset H. Z4

0.0

-10.0

10.0

PM90

Offset H. Z5

0.0

-10.0

10.0

PM91

Offset H. Z6

0.0

-10.0

10.0

INSTALLER PARAMETERS: ZONES

PZ01

Zone module logic position in the CAN network

1

0

8

PZ02

Zones number inside the module

3

1

6

PZ03

Enable auto adaptative control

Enab.

Disab.

Enab.

INSTALLER PARAMETERS: ZONE 1

PZ04

Kind of regulation
0: OFF

S/W

OFF

S/W
