Evco S.p.A.

c-pro 3 CLIMA sistema | Installer manual ver.1.1 | Code 144CP3CSE114

page 56 of 74

7.6.2

List of INSTALLER menu configuration parameters

Label

Parameter description

Default

Min

Max

I/O CONFIGURATION

I/O configuration

AIn 1

Type of analogue input configured for AIn2:

read only parameter

NTC

NTC

NTC

I/O configuration

AIn 2

Type of analogue input configured for AIn2:

read only parameter

NTC

NTC

NTC

I/O configuration

AIn 3

Type of analogue input configured for AIn3:

read only parameter

NTC

NTC

4-20mA

I/O configuration

AIn 4

Type of analogue input configured for AIn4:

read only parameter

4-20mA

4-20mA

4-20mA

I/O configuration

DIn

Type of contact for digital inputs:

NO = normally open

NC = normally closed

N.C.

N.C.

N.O.

GENERAL PARAMETERS

General parameters

Solar panels

Number of solar panel circuits present in the plant

1

0

2

General parameters

Aux 1 circuit

Enabling of auxiliary circuit 1 (aux1)

No

No

Yes

General parameters

DHW probes

Upper probe en.

Enabling of DHW tank upper probe (boiler)

Yes

No

Yes

General parameters

DHW probes

Upper probe en.

Enabling of DHW tank lower probe (boiler)

Yes

No

Yes

General parameters

Pumps alarm setup

Solar pump 1

Type of digital input for protection of solar panel circuit

circulation pump 1:

THERMAL = Protection input

FLOW = Flow switch

FLOW

THER-MAL

FLOW

General parameters

Pumps alarm setup

Solar pump 2

Type of digital input for protection of solar panel circuit

circulation pump 2:

THERMAL = Protection input

FLOW = Flow switch

FLOW

THER-MAL

FLOW

General parameters

Pumps alarms cfg

DHW pump

Type of digital input for protection of DHW circuit

circulation pump:

THERMAL = Protection input

FLOW = Flow switch

FLOW

THER-MAL

FLOW

General parameters

Pumps alarms cfg

AUX1 pump

Type of digital input for protection of AUX1 circuit

circulation pump:

THERMAL = Protection input

FLOW = Flow switch

FLOW

THER-MAL

FLOW

General parameters

CANbus address

CANbus serial address

17

0

255

General parameters

CANbus communication speed (baud rate)

125Kbit

20Kbit

500Kbit
