- 125 -
fn=112： Function 112 Storing Raster Type Graphics Data to Print Buffer
GS ( L pL pH m fn a bx by c xL xH yL yH d1...dk
[Code] < 1D>H<28>H<4C>H[d1…dk]
[Range] Parameter of GS ( L
11≦(pL+pH×256)≦65536(0≦pL≦255、0≦pH≦255)
Parameter of GS 8 L
11≦(p1+p2×256)＋p3×65536＋p4×16777216≦4294967295
(0≦p1≦255、0≦p2≦255、0≦p3≦255、0≦p4≦255)
Common parameter of GS ( L, GS 8 L
m=48
fn=112
a=48
bx=1、2
by=1、2
c=49(When monochrome color paper is specified) 、c=49、50 (When 2-color paper is specified)
1≦(xL＋xH×256)≦1024
When monochrome color paper is specified
1≦(yL+yH×256)≦1662(with by = 1)
1≦(yL+yH×256)≦831(with by = 2)
When 2-color paper is specified
1≦(yL+yH×256)≦831(with by = 1)
1≦(yL+yH×256)≦415(with by = 2)
0≦d≦255
k=(int((xL＋xHЧ256)＋7/8)Ч(yL+yH×256)
[Outline] [The specification which is common to the model]
Stores raster type graphics data to print buffer as large as x times horizontally/y times vertically.
• xL, xH specifies the horizontal direction of raster graphics data to (xL + xH x 256).
• yL, yH specifies the vertical direction of raster graphics data to (yL + yH x 256).
• “c” specifies the color of print data.
c Color of Print Data
49 1st color
50 2nd color
• 1st color denotes black (high energy) in the specified 2-color thermal paper.
• 2nd color denotes red (low energy) in the specified 2-color thermal paper.
[Caution] In STANDARD MODE, each color can be defined only once.
