- 92 -
(4) 4th byte (Paper Sensor information)
In case of MSW3-7 ON
Bit Status Hex. Decimal
0 Undefined － －
1 Undefined － －
2 Undefined － －
3 Undefined － －
4 Unused 00 0
5 Undefined － －
6 Undefined － －
7 Unused 00 0
In case of MSW3-7 OFF (CBM1000 non-compatible mode)
Bit Status Hex. Decimal
0 Reserved 01 1
1 Reserved 02 2
2 Reserved 04 4
3 Reserved 08 8
4 Fixed 00 0
5 Reserved 00 00
6 Reserved 00 00
7 Fixed 00 0
[Default] When MSW 1-3 OFF: n = 0
When MSW 1-3 ON: n = 2
[See Also] DLE EOT 、 GS ｒ
