Carrier 48/50PM C16-28 User Manual
Page 26
26
COMP
COND COIL
HUMIDI-MIZER COIL
EVAP COIL
INDOOR ENTERING
AIR
OUTDOOR AIR
METERING
DEVICE
CLOSED VALVE
OPEN VALVE
3-WAY VALVE
RH1.x
RH2.x
CV.x
C07004
Fig. 10 −
Subcooling Mode (Reheat1) — Humidi−MiZer
t System
48/50PG03−16
COMP
COND COIL
HUMIDI-MIZER COIL
EVAP COIL
INDOOR ENTERING
AIR
OUTDOOR AIR
METERING
DEVICE
CLOSED VALVE
OPEN VALVE
RH1.x
RH2.x
CV.x
a48-8174
C07005
Fig. 11 −
Hot Gas Reheat Mode (Reheat2) — Humidi−MiZer System
48/50PG03−16
48/50PG and PM
