Carrier 48/50PM C16-28 - Manual (Page 161)

161
Fan Performance — 48PMD24 — Horizontal Supply/Return Units
Airflow
(Cfm)
Available External Static Pressure (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
5500
F
937 3.26
F
988 3.56 F 1036 3.53 F 1083 3.90
G
1127 4.28
6000 1013 3.58 1060 3.96 1105 4.35
G
1149 4.75 1191 5.16
6500 1089 4.48 G 1133 4.89 G 1175 5.31 1216 5.73
H
1256 6.17
7000 G 1166 5.52
H
1207 5.96
H
1247 6.41 H 1285 6.86 1323 7.32
7500
H
1243 6.71 1282 7.18 1319 7.66 1355 8.14 1391 8.63
8000 1320 8.07 1356 8.57 1392 9.08 — — — —
8500 1398 9.60 — — — — — — — —
9000 — — — — — — — — — —
9500 — — — — — — — — — —
10000 — — — — — — — — — —
Airflow
(Cfm)
Available External Static Pressure (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
5500
G
1171 4.67 G 1212 5.06 G 1253 5.47 H 1292 5.88 H 1331 6.30
6000 1232 5.57
H
1271 6.00 H 1310 6.43 1348 6.87 1384 7.31
6500 H 1295 6.61 1333 7.06 1369 7.52 — — — —
7000 1360 7.80 1396 8.27 — — — — — —
7500 — — — — — — — — — —
8000 — — — — — — — — — —
8500 — — — — — — — — — —
9000 — — — — — — — — — —
9500 — — — — — — — — — —
10000 — — — — — — — — — —
LEGEND
Bhp - Brake Horsepower Input to Fan
Boldface indicates field-supplied drive required. NOTES:
1. Motor drive ranges:
(E) Low Range: Not Used
(F) Mid‐Low Range: 896 to 1227 rpm, 4.26 Bhp (208/230 and 460‐v), 873 to 1108
rpm, 5.75 Bhp (575‐v)
(G) Mid‐High Range: 1113 to 1414 rpm, 5.75 Bhp
(H) High Range: 1096 to 1339 rpm, 8.63 Bhp
All other rpms require field-supplied drive.
2. See General Fan Performance Notes.
Fan Performance — 48PME24 — Horizontal Supply/Return Units
Airflow
(Cfm)
Available External Static Pressure (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
5500
F
952 3.38
F
1003 3.32 F 1053 3.70 F 1100 4.09
G
1145 4.49
6000 1029 3.74 1077 4.15
G
1123 4.56 G 1167 4.98 1210 5.41
6500 1106 4.67 G 1151 5.11 1194 5.56
H
1236 6.01 H 1276 6.47
7000 G 1184 5.75
H
1226 6.23 H 1266 6.71 1306 7.19 1344 7.68
7500 H 1262 7.00 1302 7.50 1340 8.01 1377 8.53 — —
8000 1341 8.41 1378 8.95 — — — — — —
8500 — — — — — — — — — —
9000 — — — — — — — — — —
9500 — — — — — — — — — —
10000 — — — — — — — — — —
Airflow
(Cfm)
Available External Static Pressure (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
5500 G 1189 4.90 G 1232 5.31 G 1273 5.72 H 1313 6.15 1352 6.58
6000
H
1251 5.85 H 1292 6.29 H 1331 6.74 1369 7.19 — —
6500 1315 6.94 1354 7.41 1391 7.89 — — — —
7000 1381 8.18 — — — — — — — —
7500 — — — — — — — — — —
8000 — — — — — — — — — —
8500 — — — — — — — — — —
9000 — — — — — — — — — —
9500 — — — — — — — — — —
10000 — — — — — — — — — —
LEGEND
Bhp - Brake Horsepower Input to Fan
Boldface indicates field-supplied drive required. NOTES:
1. Motor drive ranges:
(E) Low Range: Not Used
(F) Mid‐Low Range: 896 to 1227 rpm, 4.26 Bhp (208/230 and 460‐v), 873 to 1108 rpm,
5.75 Bhp (575‐v)
(G) Mid‐High Range: 1113 to 1414 rpm, 5.75 Bhp
(H) High Range: 1096 to 1339 rpm, 8.63 Bhp
All other rpms require field-supplied drive.
2. See General Fan Performance Notes.
48/50PG and PM
