APPENDIX A — LOCAL DISPLAY AND CCN TABLES (CONT)
MODE — CONFIGURATION (cont)
ITEM EXPANSION RANGE UNITS DEFAULT
CCN TABLE/
SUB-TABLE
CCN POINT PAGE NO.
COOL (cont) Cooling Configuration COOL_CFG 15
B2.FN Level 2 Fans B 0 to 7 no Humidi­MiZer
FIOP:
0 (03­07)
3 (PG08­16)
6 (20, PM16)
2 (24­28)
Humidi­Mizer FIOP:
0 (03­14)
1 (PG16)
3 (20, PM16)
2 (24­28) CIR_B_2
B3.FN Level 3 Fans B 0 to 7 no Humidi­MiZer
FIOP:
0 (03­07)
3 (PG08­16)
6 (20­28, PM16)
Humidi­MiZer FIOP:
0 (03­14)
1 (PG16)
3 (20­28, PM16) CIR_B_3
CIR.C Circuit C 19
CC.LO Circuit C Lockout Temp 0 to 100F °F 0 OATLCMPC
CS.C1 Current Sensing C1 Disable/En­
able Disable (03­14,
20­28)
Enable (PG16) C1_SENSE
C1.FN Level 1 Fans C 0­7 no Humidi­MiZer
FIOP:
0 (03­14)
1 (PG16)
0 (20­28, PM16)
Humidi­MiZer FIOP:
0 (PG03­16)
1 (20­28, PM16) CIR_C_1
C2.FN Level 2 Fans C 0 to 7 no Humidi­MiZer
FIOP:
0 (03­14)
3 (PG16)
0 (20­28, PM16)
Humidi­MiZer FIOP:
0 (03­14)
1 (PG16)
2 (20­28, PM16) CIR_C_2
C3.FN Level 3 Fans C 0 to 7 no Humidi­MiZer
FIOP:
0 (03­14)
3 (PG16)
0 (20­28, PM16)
Humidi­MiZer FIOP:
0 (03­14)
1 (PG16)
3 (20­28, PM16) CIR_C_3
SST Low Suction Control 39
SST.O Suction OK Temperature 10 to 50 °F 18 SSTOK
SST.1 Low Suction ­ Level 1 10 to 50 °F 20 SSTLEV1
SST.2 Low Suction ­ Level 2 5 to 50 °F 15 SSTLEV2
SST.3 Low Suction ­ Level 3 0 to 50 °F 10 SSTLEV3
CK.DL Delay On Low SST Check 0 to 300 sec 0 SSTCKDLY
OFC Outdoor Fan Control 19
OFC.3 OFC3 Enable. CCH Dis­
able No/Yes No (PG03­16)
Yes (20­28, PM16) OFC3_CTL
0.MXP Fan Lev0 Max Pressure 100 to 500 psig 200 LEV0MAXP
1.MXP Fan Lev1 Max Pressure 100 to 500 psig 400 (PG03­16)
450 (20­28, PM16) LEV1MAXP
2.MNP Fan Lev2 Min Pressure 100 to 500 psig 150 (PG03­16)
200 (20­28, PM16) LEV2MINP
2.ON Fan Lev2 On Temperature 0 to 100 °F no Humidi­MiZer
FIOP:
55 (03­20)
45 (24­28)
Humidi­MiZer FIOP:
68 (20, PM16)
61 (24­28)(PG03­16) LEV2ON
2.OFF Fan Lev2 Off Temperature 0 to 100 °F no Humidi­MiZer
FIOP:
45 (PG03­16)
50 (20, PM16)
40 (24­28)
Humidi­MiZer FIOP:
57 (20­28,
PM16)(PG03­16) LEV2OFF
2.MXP Fan Lev2 Max Pressure 100 to 500 psig 400 LEV2MAXP
3.MNP Fan Lev3 Min Pressure 100 to 500 psig 250 LEV3MINP
