Carrier 48/50PM C16-28 - Manual (Page 119)

119
Fan Performance — 48PGF07 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1800 719 0.48 799 0.59 872 0.70 941 0.82 1006 0.94
1900 749 0.55 826 0.67 897 0.79 964 0.91 1027 1.03
2000 780 0.63 855 0.75 923 0.88 988 1.00 1049 1.13
2100 812 0.72 884 0.85 950 0.97 1012 1.10 1072 1.24
2200 844 0.82 913 0.95 977 1.08 1038 1.22 1096 1.36
2300 876 0.92 943 1.06 1005 1.20 1064 1.34 1120 1.48
2400 908 1.04 973 1.18 1033 1.32 1091 1.47 1145 1.62
2500 941 1.16 1003 1.31 1062 1.46 1118 1.61 1171 1.76
2600 974 1.29 1034 1.45 1092 1.60 1146 1.76 1198 1.92
2700 1007 1.43 1066 1.59 1121 1.76 1174 1.92 1225 2.08
2800 1040 1.59 1097 1.75 1151 1.92 1203 2.09 1252 2.26
2900 1073 1.75 1129 1.93 1181 2.10 1232 2.27 — —
3000 1107 1.93 1161 2.11 1212 2.29 — — — —
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1800 1069 1.06 1129 1.19 1187 1.33 1243 1.46 1297 1.61
1900 1088 1.16 1146 1.29 1202 1.43 1257 1.57 1310 1.72
2000 1108 1.26 1165 1.40 1220 1.54 1273 1.69 1325 1.84
2100 1129 1.38 1184 1.52 1238 1.67 1290 1.82 1340 1.97
2200 1151 1.50 1205 1.65 1257 1.80 1308 1.95 1357 2.11
2300 1174 1.63 1227 1.78 1278 1.93 1327 2.09 1375 2.25
2400 1198 1.77 1249 1.92 1299 2.08 1347 2.25 — —
2500 1223 1.92 1273 2.08 1321 2.24 — — — —
2600 1248 2.08 1297 2.24 — — — — — —
2700 1274 2.25 — — — — — — — —
2800 — — — — — — — — — —
2900 — — — — — — — — — —
3000 — — — — — — — — — —
LEGEND
Bhp - Brake Horsepower NOTES:
1. Motor drive range is 796 to 1128 rpm for low range motor/drive and 1150 to 1438
rpm for high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 2.40 for low range motor/drive and 3.10 for high range
motor/drive.
3. See General Fan Performance Notes.
Fan Performance — 48PGD08 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
2250 464 0.35 541 0.46 612 0.58 677 0.70 739 0.83
2400 479 0.40 554 0.52 622 0.64 686 0.77 745 0.90
2550 496 0.46 568 0.58 633 0.71 695 0.84 753 0.98
2700 512 0.53 582 0.65 646 0.79 705 0.92 762 1.07
2850 530 0.60 597 0.73 658 0.87 716 1.01 771 1.16
3000 547 0.68 612 0.82 672 0.96 728 1.11 782 1.26
3150 565 0.77 628 0.91 686 1.06 741 1.21 793 1.37
3300 583 0.86 644 1.01 701 1.17 754 1.32 805 1.49
3450 602 0.97 661 1.12 716 1.28 768 1.44 817 1.61
3600 621 1.08 678 1.24 732 1.41 782 1.57 831 1.75
3750 640 1.20 696 1.37 748 1.54 797 1.71 844 1.89
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
2250 797 0.96 852 1.10 905 1.25 955 1.40 1003 1.55
2400 802 1.04 856 1.19 908 1.34 957 1.49 1005 1.65
2550 808 1.13 861 1.28 912 1.43 960 1.59 1007 1.75
2700 816 1.22 867 1.37 917 1.53 965 1.70 1011 1.86
2850 824 1.31 874 1.47 923 1.64 970 1.81 1015 1.98
3000 833 1.42 882 1.58 930 1.75 976 1.93 1020 2.11
3150 843 1.53 891 1.70 937 1.88 982 2.05 1026 2.24
3300 854 1.66 900 1.83 946 2.01 990 2.19 1033 2.38
3450 865 1.79 911 1.97 955 2.15 998 2.34 1040 2.53
3600 877 1.93 922 2.11 965 2.30 1007 2.49 1048 2.69
3750 889 2.08 933 2.26 976 2.46 1017 2.65 1057 2.86
LEGEND
Bhp - Brake Horsepower
High Range Motor/Drive Required
NOTES:
1. Motor drive range is 568 to 771 rpm for low range motor/drive and 812 to 1015 rpm
for high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 2.40 for low range motor/drive and 3.10 for high range
motor/drive.
3. See General Fan Performance Notes.
48/50PG and PM
