114
Fan Performance — 48PGE04 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 452 0.09 584 0.16 693 0.23 786 0.31 870 0.38
950 460 0.10 590 0.17 698 0.25 791 0.32 874 0.40
1000 469 0.11 597 0.18 703 0.26 796 0.34 878 0.42
1050 479 0.12 604 0.20 709 0.28 801 0.36 883 0.45
1100 488 0.13 611 0.21 715 0.29 806 0.38 888 0.47
1150 498 0.15 619 0.23 721 0.31 812 0.40 893 0.49
1200 509 0.16 627 0.24 728 0.33 817 0.42 898 0.52
1250 519 0.17 635 0.26 735 0.35 823 0.44 903 0.54
1300 530 0.19 643 0.28 742 0.37 829 0.47 909 0.57
1350 542 0.21 652 0.29 749 0.39 836 0.49 915 0.59
1400 553 0.22 661 0.31 756 0.41 842 0.51 921 0.62
1450 565 0.24 670 0.33 764 0.44 849 0.54 927 0.65
1500 577 0.26 680 0.36 772 0.46 856 0.57 933 0.68
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 945 0.46 1016 0.55 1081 0.63 1143 0.72 1201 0.81
950 950 0.49 1019 0.57 1085 0.66 1146 0.75 1204 0.84
1000 954 0.51 1023 0.60 1089 0.69 1150 0.78 — —
1050 958 0.53 1028 0.63 1093 0.72 1154 0.81 — —
1100 963 0.56 1032 0.65 1097 0.75 1158 0.85 — —
1150 967 0.59 1036 0.68 1101 0.78 — — — —
1200 972 0.61 1041 0.71 1105 0.81 — — — —
1250 977 0.64 1045 0.74 1110 0.85 — — — —
1300 982 0.67 1050 0.78 — — — — — —
1350 987 0.70 1055 0.81 — — — — — —
1400 993 0.73 1060 0.84 — — — — — —
1450 999 0.76 — — — — — — — —
1500 1004 0.79 — — — — — — — —
LEGEND
Bhp - Brake Horsepower NOTES:
1. Motor drive range is 482 to 736 rpm for low range motor/drive and 796 to 1128 rpm
for high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 0.85 for low range motor/drive and 0.85 for high range
motor/drive.
3. See General Fan Performance Notes.
Fan Performance — 48PGF04 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 459 0.10 590 0.16 698 0.24 792 0.31 876 0.39
950 468 0.11 597 0.18 704 0.25 797 0.33 881 0.41
1000 477 0.12 604 0.19 710 0.27 802 0.35 885 0.43
1050 488 0.13 611 0.20 716 0.28 807 0.37 890 0.45
1100 498 0.14 619 0.22 722 0.30 813 0.39 895 0.48
1150 509 0.15 627 0.23 729 0.32 819 0.41 900 0.50
1200 520 0.17 636 0.25 736 0.34 825 0.43 906 0.53
1250 531 0.18 644 0.27 743 0.36 831 0.45 911 0.55
1300 543 0.20 653 0.28 751 0.38 838 0.48 917 0.58
1350 555 0.21 663 0.30 759 0.40 845 0.50 923 0.61
1400 567 0.23 672 0.32 767 0.42 852 0.53 930 0.63
1450 579 0.25 682 0.35 775 0.45 859 0.55 936 0.66
1500 592 0.27 692 0.37 784 0.47 867 0.58 943 0.69
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 953 0.47 1023 0.56 1089 0.64 1151 0.73 1210 0.82
950 957 0.49 1027 0.58 1093 0.67 1155 0.76 — —
1000 961 0.52 1031 0.61 1097 0.70 1159 0.80 — —
1050 965 0.54 1035 0.64 1101 0.73 1162 0.83 — —
1100 970 0.57 1040 0.67 1105 0.76 — — — —
1150 975 0.60 1044 0.69 1109 0.80 — — — —
1200 980 0.62 1049 0.73 1114 0.83 — — — —
1250 985 0.65 1054 0.76 — — — — — —
1300 990 0.68 1059 0.79 — — — — — —
1350 996 0.71 1064 0.82 — — — — — —
1400 1002 0.74 — — — — — — — —
1450 1008 0.78 — — — — — — — —
1500 1014 0.81 — — — — — — — —
LEGEND
Bhp - Brake Horsepower NOTES:
1. Motor drive range is 482 to 736 rpm for low range motor/drive and 796 to 1128 rpm
for high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 0.85 for low range motor/drive and 0.85 for high range
motor/drive.
3. See General Fan Performance Notes.
48/50PG and PM
