Fan Performance — 48PMD28 — Vertical Supply/Return Units
CFM
Available External Static Pressure (in. wg)
0.2
0.4
0.6
0.8
1.0
1.2
RPM
BHP
Drive
RPM
BHP
Drive
RPM
BHP
Drive
RPM
BHP
Drive
RPM
BHP
Drive
RPM
BHP
Drive
7500
719
2.59
A
770
2.93
A
817
3.26
A
861
3.59
A
903
3.93
B
944
4.28
B
8000
759
3.09
A
808
3.45
A
853
3.81
A
895
4.16
B
935
4.51
B
974
4.87
B
8500
799
3.65
A
846
4.03
A
889
4.41
B
930
4.79
B
969
5.16
B
1006
5.54
B
9000
840
4.28
A
884
4.68
B
926
5.09
B
966
5.48
B
1003
5.88
C
1039
6.28
C
9500
881
4.97
B
923
5.40
B
964
5.83
C
1002
6.25
C
1038
6.67
C
1073
7.09
C
10000
922
5.74
B
963
6.19
C
1001
6.64
C
1038
7.09
C
1074
7.53
C
1108
7.97
C
10500
963
6.59
C
1002
7.06
C
1040
7.54
C
1075
8.01
C
1110
8.47
C
1143
8.93
D
11000
1005
7.52
C
1042
8.01
C
1078
8.51
C
1113
9.01
D
1146
9.50
D
1178
9.98
D
11500
1046
8.53
C
1082
9.05
D
1117
9.57
D
1151
10.09
D
1183
10.60
D
1214
11.11
D
12000
1088
9.64
D
1123
10.18
D
1156
10.72
D
1189
11.26
---
---
---
---
---
---
---
CFM
Available External Static Pressure (in. wg)
1.4
1.6
1.8
2.0
2.2
2.4
RPM
BHP
Drive
RPM
BHP
Drive
RPM
BHP
Drive
RPM
BHP
Drive
RPM
BHP
Drive
RPM
BHP
Drive
7500
984
4.65
B
1025
5.05
B
1067
5.48
B
1109
5.95
C
1152
6.48
C
1197
7.06
C
8000
1013
5.25
B
1051
5.65
B
1089
6.07
C
1128
6.53
C
1167
7.02
C
1207
7.56
C
8500
1043
5.93
C
1079
6.33
C
1114
6.75
C
1150
7.20
C
1187
7.67
C
1224
8.18
C
9000
1074
6.68
C
1109
7.09
C
1142
7.52
C
1176
7.97
C
1210
8.43
C
1244
8.93
D
9500
1107
7.51
C
1140
7.93
C
1172
8.37
C
1204
8.82
D
1237
9.29
D
1269
9.78
D
10000
1140
8.41
C
1172
8.85
D
1203
9.31
D
1234
9.77
D
1265
10.24
D
1295
10.73
D
10500
1174
9.40
D
1205
9.86
D
1236
10.33
D
1265
10.80
D
1295
11.29
---
---
---
---
11000
1209
10.46
D
1239
10.95
D
1269
11.43
---
---
---
---
---
---
---
---
---
---
11500
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
12000
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
LEGEND
Bhp - Brake Horsepower Input to Fan
Rpm - Fan speed
Drive - Drive option code based on 460V motor max BHP
Grey cells indicate field-supplied pulley change required.
