141
Fan Performance — 50PG03 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
600 402 0.05 549 0.10 664 0.15 761 0.21 847 0.27
650 407 0.06 553 0.11 667 0.17 764 0.23 850 0.29
700 413 0.06 556 0.12 670 0.18 767 0.24 853 0.31
750 418 0.07 560 0.13 673 0.19 770 0.25 856 0.32
800 425 0.07 565 0.13 677 0.20 773 0.27 859 0.34
850 431 0.08 569 0.14 681 0.21 776 0.28 862 0.36
900 438 0.09 574 0.15 685 0.23 780 0.30 865 0.38
950 446 0.10 579 0.17 689 0.24 784 0.32 868 0.40
1000 454 0.11 585 0.18 693 0.25 787 0.33 872 0.42
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
600 925 0.34 997 0.41 1064 0.48 1126 0.55 1186 0.63
650 928 0.36 999 0.43 1066 0.50 1129 0.58 1188 0.66
700 930 0.38 1002 0.45 1069 0.53 1131 0.61 1191 0.69
750 933 0.40 1005 0.47 1071 0.55 1134 0.63 1193 0.72
800 936 0.42 1007 0.49 1074 0.58 1136 0.66 1196 0.75
850 939 0.44 1010 0.52 1077 0.60 1139 0.69 1198 0.78
900 942 0.46 1013 0.54 1079 0.63 1142 0.72 1201 0.81
950 945 0.48 1016 0.57 1082 0.66 1145 0.75 1204 0.84
1000 948 0.50 1019 0.59 1085 0.68 1147 0.78 — —
LEGEND
Bhp - Brake Horsepower NOTES:
1. Motor drive range is 482 to 736 rpm for low range motor/drive and 656 to 1001 rpm
for high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 0.85 for low range motor/drive and 0.85 for high range
motor/drive.
3. See General Fan Performance Notes.
Fan Performance — 50PG04 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 438 0.09 574 0.15 685 0.23 780 0.30 865 0.38
950 446 0.10 579 0.17 689 0.24 784 0.32 868 0.40
1000 454 0.11 585 0.18 693 0.25 787 0.33 872 0.42
1050 462 0.12 590 0.19 698 0.27 791 0.35 875 0.44
1100 471 0.13 596 0.20 703 0.28 796 0.37 879 0.46
1150 480 0.14 603 0.21 708 0.30 800 0.39 883 0.48
1200 489 0.15 610 0.23 713 0.32 805 0.41 887 0.50
1250 499 0.16 617 0.24 719 0.33 809 0.43 891 0.53
1300 509 0.18 624 0.26 725 0.35 814 0.45 896 0.55
1350 519 0.19 632 0.28 731 0.37 820 0.47 900 0.57
1400 529 0.21 639 0.29 737 0.39 825 0.49 905 0.60
1450 540 0.22 648 0.31 744 0.41 831 0.52 910 0.63
1500 551 0.24 656 0.33 751 0.43 837 0.54 915 0.65
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
900 942 0.46 1013 0.54 1079 0.63 1142 0.72 1201 0.81
950 945 0.48 1016 0.57 1082 0.66 1145 0.75 1204 0.84
1000 948 0.50 1019 0.59 1085 0.68 1147 0.78 — —
1050 952 0.53 1022 0.62 1088 0.71 1150 0.81 — —
1100 955 0.55 1026 0.65 1091 0.74 1153 0.84 — —
1150 959 0.57 1029 0.67 1095 0.77 — — — —
1200 962 0.60 1032 0.70 1098 0.80 — — — —
1250 966 0.63 1036 0.73 1101 0.83 — — — —
1300 970 0.65 1040 0.76 — — — — — —
1350 975 0.68 1044 0.79 — — — — — —
1400 979 0.71 1048 0.82 — — — — — —
1450 984 0.74 1052 0.85 — — — — — —
1500 988 0.77 — — — — — — — —
LEGEND
Bhp - Brake Horsepower NOTES:
1. Motor drive range is 482 to 736 rpm for low range motor/drive and 796 to 1128 rpm
for high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 0.85 for low range motor/drive and 0.85 for high range
motor/drive.
3. See General Fan Performance Notes.
48/50PG and PM
