APPENDIX A — LOCAL DISPLAY AND CCN TABLES (CONT)
MODE — OPERATING MODES (cont)
ITEM EXPANSION RANGE UNITS
CCN TABLE/
SUB-TABLE
CCN POINT
CCN WRITE
STATUS
DISPLAY
WRITE
STATUS
HEAT Heat Mode Diagnostic HEATDIAG
HEAT In Heating Mode? No/Yes IN_HEAT
OK.HT OK to Select Heat Mode? No/Yes OKTOHEAT
MS.TG Mode Select Timeguard xxx secs HEATMSTG
H.LOC Heat OAT Lockout No/Yes HEATLOCK
HT.LO Heating Lockout Temp xxx °F OATLHEAT
IDF Indoor Fan State Off/On IDFSTATE
F.SPD Commanded Fan Speed xxx % FANSPEED
AVL.H Available Heating Stages x AVLHSTGS
REQ.H Requested Heating Stages x REQHSTGS
LMT.H Max Heat Stage In Effect x HSTGLIMT
ACT.H Actual Heating Stages x ACTHSTGS
HT.1 Heat Stage 1 Relay Off/On HEAT_1
HT.2 Heat Stage 2 Relay Off/On HEAT_2
SAT Supply Air Temperature
SAT.H SAT Heat Mode Sensing Disable/
Enable SAT_HEAT
SAT Supply Air Temperature xxx.x °F SAT_DISP
SAM.L Maximum SAT Lower Level xxx.x °F SATMAX_L
SAM.U Maximum SAT Upper Level xxx.x °F SATMAX_H
SPT Space Temperature
SPT Space Temperature xxx.x °F SPACE_T forcible forcible
DMD.H Heating Demand xxx.x ^F HEAT_DMD
TRD.H Heat Demand d/dt (F/min) xxx.x HTDTREND
HT.PD SPT Heat Demand (+)
Level xx.x ^F HDEM_POS
HT.ND SPT Heat Demand (­) Level xx.x ^F HDEM_NEG
H.LAG Heat Thermal Lag Factor x.x HEAT_LAG
ECON Economizer Diagnostic ECONDIAG
EC.EN Economizer Installed No/Yes ECONO
OK.EC OK to Use Economizer? No/Yes ECONCOOL
OCC Currently Occupied No/Yes OCCUPIED forcible forcible
IDF Indoor Fan State Off/On IDFSTATE
F.SPD Commanded Fan Speed xxx % FANSPEED
COOL In Cooling Mode? No/Yes IN_COOL
OAT Outdoor Air Temperature xxx.x °F OA_TEMP forcible forcible
RAT Return Air Temperature xxx.x °F RETURN_T forcible forcible
E.LOC Econo Cool OAT Lockout No/Yes ECONLOCK
D.LOC Econo Diff Dbulb Lockout No/Yes DFDBLOCK
EH.LO Econo Cool Hi Temp Limit xxx °F OATLECLH
EL.LO Econo Cool Lo Temp Limit xxx °F OATLECLL
FC.LO Free Cool Low Temp Limit xxx °F OATLUEFC
EN.LO Econo Cool Enth Lockout No/Yes ENTHLOCK
EC.MX Econo Cool Max Position xxx % ECONOMAX
EC.MN Econo Minimum Position xxx % ECONOMIN
AQ.DV IAQ DCV Mode No/Yes IN_IAQDV
AQ.MN Econo Min IAQ Position xxx % IAQMINP
AQ.OV IAQ Override Mode No/Yes IN_IAQOV
OVR.P IAQ Override Position xxx % IAQOVPOS
AQ.LO OAQ Lockout Mode No/Yes IN_OAQLO
OAQ.L OAQ Lockout Limit xxxx OAQLOCK
LP.OV Lo Refrig Press Override No/Yes IN_LPOV
EC.CP Econo Commanded Posi­
tion xxx % ECONOCMD forcible forcible
EC.AP Econo Actual Position xxx % ECONOPOS
EC.MP Min Position in Effect xxx % MIN_POS forcible forcible
C.ANG Actuator Control Angle xx.x CTLANGLE
E.CAL Economizer Calibrating No/Yes ECOINCAL
OAU Outside Air Unit Diagnostic OAU_DIAG
OA.RN OAU System Run State 1=AUTO
2=OFF
3=TEST OAU_RUN
OA.OP OAU Operating Mode 0=Off
1=ERV
(DCV)
2=Free
Cooling
3=OA
Tempering
4=Defrost
5=Test
6=Ext.
Mode 1
7=Ext.
Mode 2
8=Ext.
Mode 3 OAU_MODE
2P.DM OAU 2­position Damper Close/
Open OAUDMPR
WHL OAU Wheel Speed xxx % OAUWHEEL
LAT OAU Leaving Air Temp xxx.x °F OAU_LAT
EXAT OAU Exhaust Air Temp xxx.x °F OAU_EXAT
OA.MN Minimum Outside Air CFM xxxxx CFM MINOACFM
DCV.M Min DCV Outside Air CFM xxxxx CFM MINDCVSP
OA.FS OAU OA Fan Speed xxx % OAFANSPD
A.OA Actual Outside Air CFM xxxxx CFM ACTOACFM
C.OA Command Outside Air CFM xxxxx CFM CMDOACFM
PE.OF Power Exhaust CFM Offset xxxxx CFM EXOFFSET
