Carrier 48/50PM C16-28 - Manual (Page 130)

130
Fan Performance — 48PGF05 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 456 0.13 574 0.20 675 0.28 766 0.37 850 0.46
1300 477 0.16 591 0.23 688 0.32 776 0.41 857 0.50
1400 500 0.18 610 0.27 703 0.36 788 0.45 867 0.55
1500 524 0.22 630 0.31 720 0.40 802 0.50 879 0.60
1600 550 0.26 652 0.35 739 0.45 819 0.55 893 0.66
1700 576 0.30 675 0.40 759 0.50 836 0.61 908 0.72
1800 604 0.35 699 0.46 781 0.57 856 0.68 925 0.79
1900 633 0.41 724 0.52 804 0.63 876 0.75 944 0.87
2000 662 0.47 750 0.59 828 0.71 898 0.83 964 0.95
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 929 0.56 1003 0.66 1073 0.76 1139 0.87 1202 0.98
1300 934 0.60 1006 0.71 1075 0.82 1140 0.93 1202 1.05
1400 941 0.65 1012 0.76 1079 0.87 1143 0.99 1204 1.11
1500 951 0.71 1020 0.82 1085 0.94 1148 1.06 1208 1.18
1600 963 0.77 1029 0.89 1093 1.01 1155 1.13 1214 1.26
1700 976 0.84 1041 0.96 1103 1.08 1163 1.21 1221 1.34
1800 991 0.91 1054 1.04 1115 1.16 1174 1.30 1230 1.43
1900 1008 0.99 1070 1.12 1129 1.25 1186 1.39 1241 1.53
2000 1026 1.08 1086 1.21 1144 1.35 1199 1.49 1253 1.63
LEGEND
Bhp - Brake Horsepower
High Range Motor/Drive Required
NOTES:
1. Motor drive range is 596 to 910 rpm for low range motor/drive, 828 to 1173 rpm for
high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 0.85 for low range motor/drive and 1.60 (single phase)
and 2.40 (3 phase) for high range motor/drive.
3. See General Fan Performance Notes.
Fan Performance — 48PGD06 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 521 0.22 628 0.31 718 0.40 800 0.49 877 0.60
1600 546 0.25 649 0.35 737 0.45 816 0.55 890 0.65
1700 572 0.30 671 0.40 757 0.50 834 0.61 906 0.72
1800 599 0.35 695 0.45 777 0.56 852 0.67 922 0.79
1900 627 0.40 719 0.51 799 0.63 872 0.74 940 0.86
2000 655 0.46 745 0.58 822 0.70 893 0.82 959 0.94
2100 684 0.53 771 0.66 846 0.78 915 0.91 979 1.03
2200 714 0.61 797 0.74 871 0.87 938 1.00 1001 1.13
2300 744 0.69 824 0.83 896 0.96 961 1.10 1022 1.24
2400 775 0.78 852 0.92 922 1.06 985 1.21 1045 1.35
2500 806 0.88 880 1.03 948 1.18 1010 1.32 1069 1.47
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 949 0.70 1018 0.82 1083 0.93 1146 1.05 1207 1.18
1600 961 0.77 1027 0.88 1091 1.00 1153 1.13 1212 1.26
1700 974 0.83 1039 0.95 1101 1.08 1161 1.21 1219 1.34
1800 988 0.91 1052 1.03 1112 1.16 1171 1.29 1227 1.43
1900 1004 0.99 1066 1.11 1125 1.25 1182 1.38 1238 1.52
2000 1022 1.07 1082 1.20 1139 1.34 1195 1.48 1249 1.62
2100 1040 1.17 1099 1.30 1155 1.44 1209 1.59 1262 1.73
2200 1060 1.27 1117 1.41 1172 1.55 1225 1.70 1277 1.85
2300 1081 1.38 1136 1.52 1190 1.67 1242 1.82 1292 1.98
2400 1102 1.50 1156 1.65 1209 1.80 1259 1.96 1309 2.12
2500 1124 1.62 1177 1.78 1228 1.94 1278 2.10 1326 2.26
LEGEND
Bhp - Brake Horsepower NOTES:
1. Motor drive range is 690 to 978 rpm for low range motor/drive and 929 to 1261 rpm
for high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 0.85 (single phase) and 2.40 (3 phase) for low range
motor/drive and 1.60 (single phase) and 2.40 (3 phase) for high range motor/drive.
3. See General Fan Performance Notes.
48/50PG and PM
