Carrier 48/50PM C16-28 - Manual (Page 134)

134
Fan Performance — 48PGE08 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
2250 408 0.28 492 0.39 567 0.50 635 0.62 699 0.74
2400 424 0.33 505 0.44 577 0.56 644 0.68 706 0.81
2550 440 0.38 519 0.50 588 0.62 653 0.75 713 0.88
2700 457 0.44 532 0.56 600 0.69 662 0.82 721 0.96
2850 473 0.50 547 0.63 612 0.77 673 0.90 730 1.05
3000 490 0.57 561 0.71 625 0.85 684 0.99 740 1.14
3150 507 0.65 576 0.79 638 0.94 695 1.08 750 1.24
3300 524 0.73 591 0.88 651 1.03 708 1.19 760 1.34
3450 542 0.82 606 0.98 665 1.13 720 1.29 772 1.46
3600 559 0.92 622 1.08 679 1.24 733 1.41 783 1.58
3750 577 1.02 638 1.19 694 1.36 746 1.53 795 1.71
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
2250 760 0.88 817 1.01 871 1.16 923 1.30 972 1.45
2400 765 0.95 820 1.09 874 1.24 924 1.39 973 1.54
2550 770 1.03 825 1.17 877 1.32 927 1.48 975 1.64
2700 777 1.11 830 1.26 881 1.42 930 1.58 977 1.74
2850 784 1.20 836 1.35 886 1.51 934 1.68 981 1.85
3000 793 1.29 843 1.45 892 1.62 939 1.79 985 1.96
3150 801 1.40 851 1.56 899 1.73 945 1.91 990 2.09
3300 811 1.51 859 1.68 906 1.85 951 2.03 995 2.21
3450 821 1.63 868 1.80 914 1.98 958 2.16 1001 2.35
3600 831 1.75 878 1.93 923 2.11 966 2.30 1008 2.49
3750 843 1.89 888 2.07 932 2.26 974 2.45 1016 2.65
LEGEND
Bhp - Brake Horsepower
High Range Motor/Drive Required
NOTES:
1. Motor drive range is 568 to 771 rpm for low range motor/drive and 812 to 1015 rpm
for high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 2.40 for low range motor/drive and 3.10 for high range
motor/drive.
3. See General Fan Performance Notes.
Fan Performance — 48PGF08 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
2250 413 0.29 496 0.39 571 0.51 639 0.63 703 0.75
2400 429 0.34 510 0.45 581 0.57 647 0.69 709 0.82
2550 446 0.39 524 0.51 593 0.63 657 0.76 717 0.89
2700 464 0.45 538 0.57 605 0.70 667 0.83 726 0.97
2850 481 0.52 553 0.65 618 0.78 678 0.92 735 1.06
3000 499 0.59 569 0.72 632 0.86 690 1.01 746 1.16
3150 517 0.67 584 0.81 646 0.95 703 1.10 756 1.26
3300 535 0.75 600 0.90 660 1.05 715 1.21 768 1.37
3450 553 0.85 617 1.00 675 1.16 729 1.32 780 1.48
3600 571 0.95 633 1.11 690 1.27 742 1.44 792 1.61
3750 590 1.06 650 1.23 705 1.40 756 1.57 805 1.74
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
2250 763 0.88 820 1.02 874 1.16 925 1.31 974 1.46
2400 768 0.96 824 1.10 877 1.25 927 1.40 976 1.55
2550 774 1.04 829 1.18 881 1.33 930 1.49 978 1.65
2700 781 1.12 834 1.27 885 1.43 934 1.59 981 1.75
2850 789 1.21 841 1.37 891 1.53 939 1.70 985 1.87
3000 798 1.31 849 1.47 897 1.64 944 1.81 990 1.98
3150 808 1.42 857 1.58 905 1.75 951 1.93 995 2.11
3300 818 1.53 866 1.70 913 1.88 958 2.06 1001 2.24
3450 829 1.65 876 1.83 921 2.01 965 2.19 1008 2.38
3600 840 1.78 886 1.96 931 2.15 974 2.34 1016 2.53
3750 852 1.92 897 2.11 941 2.30 983 2.49 1024 2.69
LEGEND
Bhp - Brake Horsepower
High Range Motor/Drive Required
NOTES:
1. Motor drive range is 568 to 771 rpm for low range motor/drive and 812 to 1015 rpm
for high range motor/drive. All other rpms require a field‐supplied drive.
2. Maximum continuous bhp is 2.40 for low range motor/drive and 3.10 for high range
motor/drive.
3. See General Fan Performance Notes.
48/50PG and PM
