Security

Parameter Settings

Parameter Links

Security

This feature provides write access protection for individual communication ports in
a drive. In addition, the following drive peripherals and software tools support this
security technology.

Communication Peripherals

20-COMM-E EtherNet/IP v2.002 (or higher)

20-COMM-C/-Q ControlNet v2.001 (or higher)

20-COMM-D DeviceNet v2.001 (or higher)

20-COMM-S DF1 v1.003 (or higher)

Software Tools

DriveExplorer v4.04 (or higher)

DriveTools SP v4.01 (or higher)

By default, every DPI port in the drive is configured to allow write access. For
additional information on DPI port locations and their assignments, refer to “HIM
Overview” in Appendix B of the User Manual.

To change write access on an individual DPI port, change the bit setting of the
associated port in [Write Mask Cfg], parameter 596.

Bit 0 = Host (drive)

Bit 1 = DPI Port 1

Bit 2 = DPI Port 2

Bit 3 = DPI Port 3

Bit 4 = DPI Port 4 (PF700VC only)

Bit 5 = DPI Port 5

Bit value of 0 = masked (read only access)

Bit value of 1 = not masked (read/write access)

Parameter

Value

Description

[Scale 1 In Hi]

2.5 V

2.5 V = 200% torque from other drive

[Scale 1 In Lo]

–2.5V

–2.5 V = –200% torque from other drive

[PI Reference Sel] 25, Scale

Block1 Out

The PI Reference becomes the output of the scale block

[PI Reference Hi]

100 %

100% PI Reference corresponds to 200% torque from other drive

[PI Reference Lo] –100 %

–100% PI Reference corresponds to –200% torque from other drive

Destination Parameter

Source Parameter Description

[Scale1 In Value]

[Analog In2 Value]

Scaling Analog In 2 value

477

476

478

460

461

2

481

Analog In2 Value

Scale1 In Hi

PI Reference Hi

Scale1 In Value

PI Reference Lo

Scale1 Out

Value

PI Reference

= Link

Scale1 In Lo
