26

DC Bus Voltage / Memory

Even if non-consecutive Datalinks are used (in the next example, Datalinks A1 and
B2 would not be used), data is still returned in the same way.

32-bit data is stored in binary as follows:

Example

Parameter 242 - [Power Up Marker] = 88.4541 hours
MSW = 13

decimal

= 1101

binary

= 2

16

+ 2

18

+ 2

19

= 851968

LSW = 32573
851968 + 32573 = 884541

DC Bus Voltage /
Memory

[DC Bus Voltage] is a measurement of the instantaneous value. [DC Bus Memory]
is a heavily filtered value or “average” bus voltage. Just after the pre-charge relay is
closed during initial power-up, bus memory is set equal to bus voltage. Thereafter it
is updated by ramping at a very slow rate toward the instantaneous bus voltage [DC
Bus Voltage]. The filtered value ramps at approximately 2.4V DC per minute (for a
480V AC drive).

Bus memory is used as a comparison value to sense a power loss condition. If the
drive enters a power loss state, the bus memory will also be used for recovery (e.g.
pre-charge control or inertia ride through upon return of the power source) upon
return of the power source. Update of the bus memory is blocked during
deceleration to prevent a false high value caused by a regenerative condition.

Digital Inputs

Digital Input Configuration

Inputs are configured for the required function by setting a [Digital Inx Sel]
parameter (one for each input). These parameters cannot be changed while the drive
is running.

Input Function Detailed Descriptions

Stop-Clear Faults

An open input will cause the drive to stop and become “not ready”. A closed
input will allow the drive to run when given a Start or Run command.

If “Start” is configured, then “Stop - Clear Faults” must also be configured.
Otherwise, a digital input configuration alarm will occur. “Stop - Clear Faults”
is an optional setting in all other cases.

An open to closed transition is interpreted as a Clear Faults request. The drive
will clear any existing faults.

If the “Clear Faults” input function is configured at the same time as “Stop -
Clear Faults”, then it will not be possible to reset faults with the “Stop - Clear
Faults” input.

Datalink

Most/Least Significant Word Parameter

Data (decimal)

A1

-Not Used-

0

0

A2

MSW

242

13

Datalink

Most/Least Significant Word Parameter

Data (decimal)

A2

MSW

242

13

B1

LSW

242

32573

MSW

2

31

through 2

16

LSW

2

15

through 2

0

70EC

700VC

700H

✔ ✔

70EC

700VC

700H

✔ ✔
