1
Publication 1756-UM521C-EN-P - July 2004
Appendix
C
Configuring the Daisy Chain Configuration
This appendix provides a sample configuration for a SynchLink system using
the Daisy Chain Configuration. The system’s physical configuration is shown
in Figure C.1. In this configuration, you must:
• configure the Master Node in an RSLogix 5000 project.
• configure the Center Node in an RSLogix 5000 project.
• configure the End Node in an RSLogix 5000 project.
Figure C.1
42883
Master Node
ControlNet
SynchLink
Center Node
End Node
The SynchLink module in
this chassis is configured
as the Time Master for
the for the SynchLink.
The SynchLink modules in these chassis
are configured as the CST Time Masters.
