Rockwell Automation 1756-SYNCH ControlLogix SynchLink Module User Manual User Manual
Page 107
Publication 1756-UM521C-EN-P - July 2004
Configuring the Daisy Chain Configuration C-13
Add a SynchLink Module
1. Select a SynchLink module as shown below.
A. Select I/O Configuration.
B. Click on the right mouse button
to display the menu.
C. Select New Module
A. Select a 1756-SYNCH module
Make sure the Ma-
jor Revision number
matches the label
on the side of your
module
B. Click here
