Rockwell Automation 1756-SYNCH ControlLogix SynchLink Module User Manual User Manual
Page 7
Publication 1756-UM521C-EN-P - July 2004
Preface 3
5. Expand the network until you see the module. If the required
network is not shown, first configure a driver for the network in
RSLinx software.
6. Select the controller and choose OK.
7. Select the revision level to which you want to update the
1756-SYNCH module and choose Next >.
8. To start the update of the module, choose Finish and then Yes.
After the module is updated, the status box displays
Update complete.
9. Choose OK.
10. To close ControlFLASH software, choose Cancel and then Yes
IMPORTANT
If the Revision list is empty, download a new
upgrade kit. Some older upgrade kits do not work
with new modules.
