Rockwell Automation 1756-SYNCH ControlLogix SynchLink Module User Manual - Manual (Page 29)

1 Publication 1756-UM521C-EN-P - July 2004
Chapter
3
SynchLink Module Features
This chapter describes the ControlLogix SynchLink module features.
Configurable module features are features (e.g. Communications
Format) that can be configured to work differently in various
SynchLink applications.
Table 3.1
For information on: See page:
Module Features That Cannot Be Configured 3-2
Removal and Insertion Under Power (RIUP) 3-2
Module Fault Reporting 3-3
Full RSLogix 5000 Support 3-3
Status Indicator (LED) Information 3-4
Class I Division 2 Certification 3-4
Agency Certification 3-4
Use Last Configuration When Connection to Owner-Controller
Closes - For Module’s Using Firmware Revision 2.18 or Greater 3-5
Module Features That Can Be Configured 3-5
Communications Format 3-6
Electronic Keying 3-11
Requested Packet Interval 3-13
SynchLink Transmitted Axes 3-15
Transmitted Direct Words 3-16
CST and SynchLink Mastership 3-18
