Rockwell Automation 1756-SYNCH ControlLogix SynchLink Module User Manual User Manual
Page 126
Publication 1756-UM521C-EN-P - July 2004
D-16 Configuring the Ring Configuration
Download Configuration
Download the configuration data.
RSLogix 5000 verifies the download process with this pop-up screen.
This completes the download process.
When all the chassis in the Ring Configuration are configured and operating
online (i.e. configuration was downloaded) the chassis synchronize with the
CST Time Master.
Pull down this menu and click
here to download the new data
Click here to download new
