Rockwell Automation 1756-SYNCH ControlLogix SynchLink Module User Manual - Manual (Page 49)

1 Publication 1756-UM521C-EN-P - July 2004
Chapter
4
Installing the SynchLink Module
This chapter describes how to install the ControlLogix
SynchLink module.
Noting the Power
Requirements This module receives power from the 1756 chassis power supply and requires
2 sources of power from the backplane:
• 1200mA at 5.1V dc
• 3mA at 24V dc
Add this current/power value (6.19W) to the requirements of all other
modules in the chassis to prevent overloading the power supply.
Table 4.1
For information on: See page:
Noting the Power Requirements 4-1
Installing the Module 4-2
Connecting the Fiber Optic Cable 4-3
Removing the Module 4-4
IMPORTANT
Before you install and use your module you should have
already installed and grounded a 1756 chassis and power
supply.
To install these products, refer to the products’ user
documentation, as listed in Table Preface.3 on
page Preface-5.
