Rockwell Automation 1756-SYNCH ControlLogix SynchLink Module User Manual User Manual
Page 125
Publication 1756-UM521C-EN-P - July 2004
Configuring the Ring Configuration D-15
Click here to move to the next page
Click here to move to the next page
The module transmits 2 Direct
Words, as specified in the transmit
port communications format.
The Module Identification page
is blank during initial
Time slave modules must be
configured as Time Masters
for their respective chassis if
you want to synchronize each
chassis’ CST time value with
the CST Time Master.
Click here to finish configuration.
