1

Publication 1756-UM521C-EN-P - July 2004

Chapter

1

What is the 1756-SYNCH module?

This chapter describes the ControlLogix SynchLink module. It also describes
what you must know and do before using the SynchLink module.

What is the ControlLogix
SynchLink Module?

A ControlLogix SynchLink module, through the use of fiber optic
communication technology, allows you to implement:

• time synchronization
• distributed motion control
• coordinated drive control

based on the ControlLogix and PowerFlex 700S platforms. In distributed
control system, the SynchLink module broadcasts reference data and
synchronizes time from a single ControlLogix chassis to multiple other chassis
at a high speed.

What Data Does the SynchLink Module Transfer?

The SynchLink module transfers multiple types of reference data between
chassis, including:

• Produced axis data for chassis to chassis remote axis control
• High speed drive reference data for chassis to drive control
• General control information that requires transfer at a high speed and in

a synchronized manner

Table 1.1

For information on:

See page:

What is the ControlLogix SynchLink Module?

1-1

Connecting a SynchLink Module to a SynchLink System

1-3

Using Module Identification and Status Information

1-5

Preventing Electrostatic Discharge

1-6

Removal and Insertion Under Power

1-6
