Rockwell Automation 1791DS-IBxxxx Guard I/O DeviceNet Safety Modules User Manual
Page 65
Rockwell Automation Publication 1791DS-UM001J-EN-P - May 2013
65
Configure Modules with the Logix Designer Application
Chapter 5
5. Assign the input data.
Choose
Description
Safety
These tags are created for the target module:
·RunMode for module mode
·ConnectionFaulted for communication status
·Safety Data for safety inputs from the module
