152 Rockwell Automation Publication 1791DS-UM001J-EN-P - May 2013
Appendix A Get Point Status from Modules by Using Explicit Messaging
1732DS-IB8, 1732DS-IB8XOBV4, 1791DS-IB8XOBV4, and 1791DS-IB16
Data
The bits in the tag definitions of the Logix Designer application and RSNetWorx
software are different than those shown in this section. This table defines the
name associations for clarification with the programming software.
These tables provide reference data concerning input and output data.
Bit Definitions Logix Designer Application Tag Name
Safety Input 0…7 Module Name:I.Pt00Data - Pt15Data
Safety Input 0…7 Status Module Name:I.Pt00InputStatus - Pt15InputStatus
Combined Safety In Status Module Name:I.InputStatus
Muting Lamp Status Module Name:I.MutingStatus
Safety Output 0…7 Module Name:O.Pt00Data - Pt07Data
Safety Output 0…7 Status Module Name:I.Pt00OutputStatus - Pt07OutputStatus
Combined Safety Out Status Module Name:I.OutputStatus
Safety Output 0…7 Readback Module Name:I.Pt00Readback - Pt07Readback
Test Output 0…7 Data Module Name:I.Test00Data - Test07Data
Test Output 0…7 Status Module Name:I.Pt00TestOutputStatus - Pt07TestOutputStatus
Table 20 - Input Data for 1732DS-IB8, 1732DS-IB8XOBV4, 1791DS-IB8XOBV4, 1791DS-IB16 Modules
Instance Hex
(decimal) Module Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
204
(516) 1732DS-IB8,
1732DS-IB8XOBV4,
1791DS-IB8XOBV4 0 Safety Input
7 Safety Input 6 Safety Input
5
Safety Input 4 Safety Input
3
Safety Input 2 Safety Input 1 Safety Input 0
224
(548) 0 Safety Input
7 Safety Input 6 Safety Input
5
Safety Input 4 Safety Input
3
Safety Input 2 Safety Input 1 Safety Input 0
1 Safety Input
7 Status Safety Input 6
Status Safety Input
5 Status Safety Input 4
Status Safety Input
3 Status Safety Input 2
Status Safety Input 1
Status Safety Input 0
Status
205
(517) 1791DS-IB16 0 Safety Input
7 Safety Input 6 Safety Input
5
Safety Input 4 Safety Input
3
Safety Input 2 Safety Input 1 Safety Input 0
Safety Input
15 Safety Input
14 Safety Input
13 Safety Input
12 Safety Input
11 Safety Input
10 Safety Input 9 Safety Input 8
225
(549) 1791DS-IB16 0 Safety Input
7 Safety Input 6 Safety Input
5
Safety Input 4 Safety Input
3
Safety Input 2 Safety Input 1 Safety Input 0
1 Safety Input
15 Safety Input
14 Safety Input
13 Safety Input
12 Safety Input
11 Safety Input
10 Safety Input 9 Safety Input 8
2 Safety Input
7 Status Safety Input 6
Status Safety Input
5 Status Safety Input 4
Status Safety Input
3 Status Safety Input 2
Status Safety Input 1
Status Safety Input 0
Status
3 Safety Input
15 Status Safety Input
14 Status Safety Input
13 Status Safety Input
12 Status Safety Input
11 Status Safety Input
10 Status Safety Input 9
Status Safety Input 8
Status
300
(768) 1732DS-IB8,
1791DS-IB16 0 Reserved Input Power
Error
301
(769) 1732DS-IB8,
1732DS-IB8XOBV4,
1791DS-IB8XOBV4 0 Reserved Output Power
Error Input Power
Error
314
(788) 1732DS-IB8 0 Safety Input
7 Safety Input 6 Safety Input
5
Safety Input 4 Safety Input
3
Safety Input 2 Safety Input 1 Safety Input 0
1 Reserved Muting Lamp 7
Status Muting Lamp 3
Status
