Rockwell Automation 21G PowerFlex 750-Series AC Drives User Manual
Page 78

78
Rockwell Automation Publication 750-IN001N-EN-P - April 2014
PowerFlex 750-Series AC Drives
Figure 45 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 8
Enclosure Code B with P14 - 600 mm Deep Drive with Wiring Bay.
M12 (1/2 in.) Property Class 8.8 anchoring hardware recommended to
fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts may be pre-located and embedded in the
foundation prior to instillation.
2453
(96.6)
2300
(90.6)
600
(23.6)
240
(9.4)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
ø18.0
(0.71)
542
(21.3)
43
(1.7)
69
(2.7)
500
(19.7)
460
(18.1)
398
(15.7)
141
(5.6)
127
(5.0)
344
(13.5)
➊
➊
➊
➋
➊
➊
➋
➎
➍
76
(3.0)
1200
(47.2)
440
(17.3)
440
(17.3)
127
(5.0)
76
(3.0)
68
(2.7)
183
(7.2)
183
(7.2)
1464
(57.6)
➌
No.
Description
➊
Power wiring conduit plates.
➋
Control wiring conduit plates.
➌
Optional exhaust hood.
➍
Optional HIM.
➎
Recommended four-hole anchoring.
BOTTOM
TOP
BOTTOM
