Rockwell Automation Publication 750-IN001N-EN-P - April 2014 179
PowerFlex 750-Series AC Drives
Input Power Circuit Breakers and Disconnect Switches
Refer to page 12 for an explanation of where to locate drive ratings on the
nameplate.
Table 15 - 400V, 50 Hz Input - Code P3 Thermal Magnetic Circuit Breaker Options
Table 16 - 400V, 50 Hz Input - Code P5 Molded Case Disconnect Switch Options (Floor Mount Frame
8 Only)
kW Amps Duty Line Side Terminal
Lugs Terminal Size Recommended Torque
200 385 Heavy 140U-L-TL6A2 (2) 2…500 MCM kit of 3 42 N•m (375 lb•in)
250 460 Normal 140U-L-TL6A2 (2) 2…500 MCM kit of 3 42 N•m (375 lb•in)
456 Heavy 140U-L-TL6A2 (2) 2…500 MCM kit of 3 42 N•m (375 lb•in)
472 Heavy 140U-L-TL6A2 (2) 2…500 MCM kit of 3 42 N•m (375 lb•in)
315 540 Light 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
540 Normal 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
540 Heavy 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
315 585 Light 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
567 Normal 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
585 Heavy 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
355 612 Light 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
650 Normal 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
642 Heavy 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
400 750 Light 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
750 Normal 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
770 Normal 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
450 796 Light 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
832 Light 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
kW Amps Duty Line Side Terminal
Lugs Terminal Size Recommended Torque
200 385 Heavy 140U-L-TL6A2 (2) 2…500 MCM kit of 3 42 N•m (375 lb•in)
250 460 Normal 140U-L-TL6A2 (2) 2…500 MCM kit of 3 42 N•m (375 lb•in)
456 Heavy 140U-L-TL6A2 (2) 2…500 MCM kit of 3 42 N•m (375 lb•in)
472 Heavy 140U-L-TL6A2 (2) 2…500 MCM kit of 3 42 N•m (375 lb•in)
315 540 Light 140U-M-TLA2A (2) 500…750 MCM 56 N•m (500 lb•in)
540 Normal 140U-M-TLA2A (2) 500…750 MCM 56 N•m (500 lb•in)
540 Heavy 140U-M-TLA2A (2) 500…750 MCM 56 N•m (500 lb•in)
315 585 Light 140U-M-TLA2A (2) 500…750 MCM 56 N•m (500 lb•in)
567 Normal 140U-M-TLA2A (2) 500…750 MCM 56 N•m (500 lb•in)
585 Heavy 140U-M-TLA2A (2) 500…750 MCM 56 N•m (500 lb•in)
355 612 Light 140U-M-TLA2A (2) 500…750 MCM 56 N•m (500 lb•in)
650 Normal 140U-M-TLA2A (2) 500…750 MCM 56 N•m (500 lb•in)
642 Heavy 140U-M-TLA2A (2) 500…750 MCM 56 N•m (500 lb•in)
400 750 Light 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
750 Normal 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
770 Normal 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
450 796 Light 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
832 Light 140U-N-TLA3A (3) 500…750 MCM 42 N•m (375 lb•in)
