Rockwell Automation Publication 750-IN001N-EN-P - April 2014

31

PowerFlex 750-Series AC Drives

Attach Lifting Hardware

Figure 13 - Rigging Geometry

Enclosure Code F

Wall Mount Frame 6 Lifting Points – 2 Places

Wall Mount Frame 7 Lifting Points – 4 Places

>1/2 A

A

<45°

>1/2 A

A

<45°
