Rockwell Automation 21G PowerFlex 750-Series AC Drives User Manual
Page 172
172
Rockwell Automation Publication 750-IN001N-EN-P - April 2014
PowerFlex 750-Series AC Drives
Drive Catalog
Number
Duty
Cycle
Hp
Short Circuit Current Rating (kA)
Circuit Breaker
Only (P3)
(1)
Circuit Breaker with Input Contactor
(P3 with P11)
(1)
Molded Case Switch Only
(P5)
(2)
Molded Case Switch with Input Contactor
(P5 with P11)
(2)
480 Volt AC Input
21G…D430
LD
400
100
30 or
• 65 w/600 A Class J fuse
65
5 or
• 65 w/600 A Class J fuse
• 30 w/600…1000 A Class L fuse
• 30 w/600…1200 A CB
ND
350
100
30 or
• 65 w/550…600 A Class J fuse
65
30 or
• 65 w/550…600 A Class J fuse
HD
300
100
5 or
• 100 w/450…600 A Class J fuse
• 18 w/600…800 A Class L fuse
• 18 w/500 A CB
65
5 or
• 100 w/500…600 A Class J fuse
• 18 w/600…800 A Class L fuse
• 18 w/500 A CB
21G…D485
LD
450
100
30
65 or
• 100 w/800 A Class L fuse
5 or
• 30 w/650…1200 A Class L fuse
• 30 w/700…1200 A CB
ND
400
100
30 or
• 65 w/600 A Class J fuse
65
5 or
• 65 w/600 A Class J fuse
• 30 w/600…1000 A Class L fuse
• 30 w/600…1200 A CB
HD
350
100
5 or
• 100 w/500…600 A Class J fuse
• 18 w/600…900 A Class L fuse
65
5 or
• 100 w/500…600 A Class J fuse
• 18 w/600…900 A Class L fuse
21G…D545
LD
500
100
30
65 or
• 100 w/800 A Class L fuse
5 or
• 30 w/700…1300 A Class L fuse
• 30 w/700…1200 A CB
ND
450
100
30
65 or
• 100 w/650…800 A Class L fuse
5 or
• 30 w/650…1200 A Class L fuse
• 30 w/700…1200 A CB
HD
350
100
30 or
• 65 w/550…600 A Class J fuse
65
5 or
• 65 w/550…600 A Class J fuse
• 30 w/600…1000 A Class L fuse
• 30 w/600…1200 A CB
21G…D617
LD
600
100
42
65 or
• 100 w/850…1200 A Class L fuse
5 or
• 42 w/850…1500 A Class L fuse
• 42 w/900…1200 A CB
ND
500
100
30
65 or
• 100 w/750…800 A Class L fuse
5 or
• 30 w/750…1300 A Class L fuse
• 30 w/800…1200 A CB
HD
400
100
30 or
• 65 w/600 A Class J fuse
65
5 or
• 65 w/600 A Class J fuse
• 30 w/600…1000 A Class L fuse
• 30 w/600…1200 A CB
21G…D710
LD
650
100
42
65 or
• 100 w/1000…1200 A Class L fuse
5 or
• 42 w/1000…1700 A Class L fuse
• 42 w/1000…2000 A CB
ND
600
100
42
65 or
• 100 w/850…1200 A Class L fuse
5 or
• 42 w/850…1500 A Class L fuse
• 42 w/900…1200 A CB
HD
450
100
30
65 or
• 100 w/650…800 A Class L fuse
5 or
• 30 w/650…1200 A Class L fuse
• 30 w/700…1200 A CB
21G…D740
LD
700
100
42
65 or
• 100 w/1000…1200 A Class L fuse
5 or
• 42 w/1000…1700 A Class L fuse
• 42 w/1000…2000 A CB
ND
650
100
42
65 or
• 100 w/900…1200 A Class L fuse
5 or
• 42 w/900…1600 A Class L fuse
• 42 w/900…2000 A CB
HD
500
100
30
65 or
• 100 w/750…800 A Class L fuse
5 or
• 30 w/750…1300 A Class L fuse
• 30 w/800…1200 A CB
continued on
page 173
