Rockwell Automation 21G PowerFlex 750-Series AC Drives User Manual
Page 150
150
Rockwell Automation Publication 750-IN001N-EN-P - April 2014
PowerFlex 750-Series AC Drives
Figure 91 - Top And Bottom Entry Power Connection Example
IMPORTANT
Verify that all lug fasteners and L-brackets are properly torqued to 38.0 N•m (336
lb•in). Torque down or remove any unused L-brackets.
AC Input
AC Output
DC Input
