Dimensions are in millimeters and (inches), Figure 30 - flange mount, frame 7 – Rockwell Automation 21G PowerFlex 750-Series AC Drives User Manual
Page 62
62
Rockwell Automation Publication 750-IN001N-EN-P - April 2014
PowerFlex 750-Series AC Drives
Figure 30 - Flange Mount, Frame 7
Dimensions are in millimeters and (inches).
875.0
(34.45)
430.0
(16.93)
208.4
(8.20)
138.0
(5.43)
509.6
(20.06)
28.0
(1.10)
431.2
(16.98)
352.8
(13.89)
274.4
(10.80)
196.0
(7.72)
117.6
(4.63)
588.0
(23.15)
666.4
(26.24)
744.8
(29.32)
784.0
(30.87)
812.0
(31.97)
39.2
(1.54)
768.0
(30.24)
50.38 (1.98)
151.13 (5.95)
251.88 (9.92)
352.63 (13.88)
403.00 (15.87)
32x: Ш7.0
(Ш0.28)
387.0
(15.24)
8.0
(0.31)
8.0
(0.31)
IMPORTANT
Must use Flange Adapter kit (20-750-FLNG4-F7) to meet enclosure rating.
