PowerFlex 750-Series AC Drives
Drive Catalog
Number
Duty
Cycle
Hp
Short Circuit Current Rating (kA)
Circuit Breaker
Only (P3)
(1)
Circuit Breaker with Input Contactor
(P3 with P11)
(1)
Molded Case Switch Only
(P5)
(2)
Molded Case Switch with Input Contactor
(P5 with P11)
(2)
600 Volt AC Input
21G…E295
LD
350
50
• 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
ND
300
50
• 18 w/600 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
HD
250
50
• 18 w/600 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
21G…E355
LD
400
50
• 18 w/601…800 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
ND
350
50
• 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
HD
300
50
• 18 w/600 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
21G…E395
LD
450
50
• 30 w/601…900 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse
• 30 w/800 A Class L fuse
ND
400
50
• 18 w/601…800 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
HD
350
50
• 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
21G…E435
LD
500
50
• 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse
• 30 w/800 A Class L fuse
ND
450
50
• 30 w/601…900 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse
• 30 w/800 A Class L fuse
HD
350
50
• 18 w/601…700 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
21G…E460
LD
500
35
• 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse
• 30 w/800 A Class L fuse
ND
500
50
• 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse
• 30 w/800 A Class L fuse
HD
400
50
• 18 w/601…800 A Class L fuse
• 18 w/500 A CB
• 100 w/600 A Class J fuse
25
• 25 w/600 A Class J fuse
21G…E510
LD
550
35
• 30 w/601…1100 A Class L fuse
• 30 w/1100 A CB
• 100 w/800 A max Class L fuse
• 30 w/800 A Class L fuse
ND
500
35
• 30 w/601…1000 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse
• 30 w/800 A Class L fuse
HD
450
50
• 30 w/601…900 A Class L fuse
• 30 w/1000 A CB
• 100 w/800 A max Class L fuse
• 30 w/800 A Class L fuse
21G…E595
LD
700
50
–
–
–
ND
600
50
–
–
–
HD
500
50
–
–
–
21G…E630
LD
800
50
–
–
–
ND
700
50
–
–
–
HD
600
50
–
–
–
21G…E760
LD
900
50
–
–
–
ND
800
50
–
–
–
HD
700
50
–
–
–
