Rockwell Automation Publication 750-IN001N-EN-P - April 2014 171
PowerFlex 750-Series AC Drives
continued on page 171
21G…C910 LD 560 100 – – –
ND 500 100 – – –
HD 400 100 – – –
21G…C1K0 LD 630 100 – – –
ND 560 100 – – –
HD 500 100 – – –
21G…C1K1 LD 710 100 – – –
ND 630 100 – – –
HD 500 100 – – –
21G…C1K2 LD 800 100 – – –
ND 710 100 – – –
HD 560 100 – – –
21G…C1K4 LD 850 100 – – –
ND 800 100 – – –
HD 630 100 – – –
21G…C1K5 LD 900 100 – – –
ND 850 100 – – –
HD 710 100 – – –
(1) These circuit breakers are considered Branch Circuit Protection for the unit.
(2) No additional protection is provided with the P5 Molded Case Switch option. Branch circuit protection is required based on NEC guidelines.
Drive Catalog
Number Duty
Cycle
kW
Short Circuit Current Rating (kA)
Circuit Breaker
Only (P3)
(1)
Circuit Breaker with Input Contactor
(P3 with P11)
(1)
Molded Case Switch Only
(P5)
(2)
Molded Case Switch with Input Contactor
(P5 with P11)
(2)
400 Volt AC Input
