Page 21
EAGLE 2 Operator’s Manual
Instrument Description • 11
Printed Circuit Boards (PCBs)
Figure 4: EAGLE 2 PCBs
The EAGLE 2’s PCBs analyze, record, control, store, and display the
information collected. The main PCB and I.S. barrier PCB are located in the
bottom case. The display PCB is located in the top case. The display PCB and
I.S. barrier PCB are not user serviceable and are not involved in any user
performed maintenance. The main PCB is not user serviceable, but it is
involved in the replacement of sensors, so it is described below.
Main PCB
Display PCB
I.S. Barrier PCB (not visble)
