66 5 Program Overview
5.1 Pr
ogr
amming Intr
oduction
Run Options soft keys
The Run Options soft key allows the program to be run and tested with
various options for a program. These options allow the operator to test
a program without actually cutting material. The Run Options must be
set before you start to run the program.
Soft key Function
The Single Step soft key will move the machine one
step at a time.
The Dry Run soft key will run the program’s tool path
at the speed defined in Job Setup. No material
should be placed within the tool path for this
function. Dry Run is intended to provide a quick
verification of the machine movements in the
program.
The Graphics Only soft key will run through the
program drawing the tool movement on the display
only. Graphics Only is intended to provide a quick
verification of the tool path in the display; no
machine movement will occur.
The Optional Stop soft key will allow the program
to be stopped at different locations to allow for
verification of particular program steps selected has
the operator. If a program has an optional stop (i.e.:
M01 in a G-code program), the system will only stop
at this block when Optional Stop is enabled. If it is
disabled, it will be skipped. The Optional Stop is an
M01 in a G-code program.
The Exit soft key will exit the Run Options function
and return to the previous display.
