ACU-RITE MILLPWR G2 5
1
.1 MILLPWR
G2
Emergency Stop (E-STOP)
 Press E-STOP to take all axes servos offline. This ends
all machine movement, and allows the quill to be
raised to move the tool out of the way.
 To reset the E-STOP, turn the rotary switch clockwise in the direction
of the arrows. The switch pops outward, and is reset.
 Resetting E-STOP does not reactivate the servos.
Activating/Resetting the Servos
For safety reasons, the mill powers up with the servomotors
disengaged. While the servos are disengaged the mill axes cannot
move under servo power. The axes can be manually positioned if
necessary.
Reset the servos as follows:
 If a limit switch disengaged the servos, manually reposition the
machine inside its normal range of travel.
 If a miscount occurs, press the Find Home soft key to reset the
servos and return all axes to their home position.
