116 7 Demonstration Program
7.
1 Demonstr
ation Pr
ogr
am
Programming the lower angle Line
Next, the line that angles in to the part from the lower vertical line will
be added.
 Press the LINE key.
MILLPWR
G2
has again assumed that it will continue from where it left
off, and all fields are filled in except for the TO: fields. The cursor is also
located here, in the first field.
Using the numerical keypad, enter the following information:
 In the TO: X2 field enter .75.
 Now press the ABS/INCR key.
 The INC field next to the X2 field has opened. Press the X1 soft key.
X1 is displayed in this field next to the X2 field.
 ARROW Down once to the Y2 field.
 In the TO: Y2 field enter 0.00.
 Press the USE key.
Next, the upper angle line will be added to the program.
If the X1 soft key had not been pressed, then INCR would
not have been used, and MILLPWR
G2 would assume that
ABS is to be continued.
