Qs2.2 program generator configuration window – Campbell Scientific CR9000X Measurement and Control System User Manual
Page 21
Quick Start
QS2.2 Program Generator Configuration Window
Colors match the colors of the module names to
the right. The modules must be inserted into the
slot shown.
Enter the size of the PCMCIA memory card used in
the CR9032 module's PC card slot. This value will
be used to estimate the amount of remaining
memory in the Output Tables window.
When checked, these
boxes create the code to
perform special
functions. We will be
selecting some of these
later.
Enter a 2 for the
CPU Type
(CR9032 CPU).
Enter the number
and type of
modules that you
will be using in
your CR9000X.
Click on Done
to save your
selections.
